進口數控機床報警信息中英文對照

平時在操作數控機床,特別是進口機床時,總會遇到報警的信息提示,有些英文的對照不免讓新學者頭疼,小編特意整理了一些常見的數控機床報警信息中英文對照版的,沒事翻翻就當小小工具書了!



T WORD ERROR (T 碼錯誤)

LOW OIL LEVEL (油位低)

SPINPLE FAULT (主軸故障)

SPINDLE ALARM (主軸報警)

EXTERNAL EMG STOP (急停按鈕被按下)

AC NOT READY (交流盤未準備好)

SPINPLE LUBE FAULT (主軸潤滑故障)

T CODE ERROR (T代碼出錯,非法T代碼)

M CODE ERROR (M代碼出錯,非法M代碼)

SERVO NOT READY (伺服未準備好)

NC NOT READY(NC沒準備好)

TURRET FAULT (轉塔故障)

TURRET LIMIT (轉塔限位)

DC 24V OPEN (直流24斷開)

+24V NOT READY(+24V沒準備好)

GRAR DRIFT (檔位漂移)

PLEASE AXIS RETURN HOME(軸未回零)

PLEASE DRUM RETURN HOME(刀庫未回零)


AIR PRESSURE DROP (壓縮空氣壓力過低)

CLAMP TOOL FALL(夾刀失?。?/span>

DRUM NOT PARKED(刀庫未在原值)

X ZERO POINT NOT REACHED (X 軸未回零)

Y ZERO POINT NOT REACHED (Y 軸未回零)

Z ZERO POINT NOT REACHED (Z 軸未回零)

4TH ZERO POINT NOT REACHED (第4軸未回零)

X AXIS OVERTRAVL(X軸超限)

Y AXIS OVERTRAVL (Y軸超限)

Z AXIS OVERTRAVL (Z軸超限)

COUNTER SWITCH REEOR (計數開關故障)

MASTERT RANSFER OVER TEMP (主變壓器過熱)

Z AXIS NOT AT FIRST REF POSITION (Z軸未在第一參考點)

SPINDLE ORIENTATION FALLURE (主軸定向失敗)

TOOL DESENT OR TOOL DATA REEOR (刀具數據錯誤)

PLEASE UNLOAD THE TOOL ON SPRINELK (請卸下主軸上的刀)

PLEASE LOAD TOOL ON APINDLE (請裝上主軸上的刀)

A AXIS UNCLAMP FAIL (A 軸松開失?。?/span>

A AXIS CLAMP FAIL (A 軸夾緊失?。?/span>

DRUM OUT TO APRONDLEIS FALL (刀庫擺向換刀位失?。?/span>


MG SWING OVERLOAD(刀庫擺動過載)

DRUM BACK PARK IS FALL (刀庫擺回原始位失?。?/span>

TURRENT MOTOR1 OVERLOAD (刀庫移動電機過載)

COOLANT MOTOR OVERLOAD (冷卻泵過載)

DRUM ATC FAULT (自動換刀失?。?/span>

TOOLS UNLOCKED (刀具未鎖緊)

BATTERY ALARM (電池報警)

DRUM POSITION SWITCH ERROR (刀庫位置檢測開關故障)

DRUM NOW NOT AT PARK (刀庫未在原始位置)

IT DANGOU TO MOVE DRUM (刀庫禁動)

POT UO FAILOR POT NOT AT UP POSITION (刀套未在水平位)

POT DOWN FAIL (刀套翻下動作失?。?/span>

IT IS DANGOUR TO MOVE ARM (機械手禁動)

THE SPINDLE STATU IS ERROR (主軸狀態錯誤)

ARM MOTOR OR ARM SWITCH FALL (機械手或機械手開關故障)

CENTRE LUBRICATION FALL (中心潤滑故障)

THE WORK NOT CLAMPED (工件未夾緊)

AUTO TOOL CHANGE FAULT (自動換刀失?。?/span>

TOOL DATA OUT OF RANGE (指令刀具號超出范圍)

THE ORDER TOOL NOW IN SPINDLE (目標刀具在主軸上)


THE THREE SPINDLE SWITCH FAULT (主軸上的接近開關)

THE CENTRE COOLANT IS LOWER (刀具內冷泵液位過低)

DRUM RETURN 1# POSITION FAULT (刀庫自動回零失?。?/span>

SPINDLE OVERLOAD (主軸過載)

TURRENT MOTOR OVERLOAD (刀盤轉動電機過載)

CHIP CONVEYER OVERLOAD (拉屑器過載)

HARD LIMIT OR SERVO ALARM (硬限位或伺服報警)

NO LUB OIL (無潤滑油)

INDEX HEAD UNLOCKED (分度頭未鎖緊)

MT NOT READY(機床沒準備好)

MG OVERLOAD (刀庫過載)

LUB EMPTY(潤滑無油)

AIR PRESSURE(氣壓不足)

COOLANT NOT READY(冷卻沒準備好)

LUBE EMPTY(油霧油位低,潤滑油位低)

LUB PRESSURE LOW(潤滑壓力低)

CONVEY VERLOAD(排屑過載)

LUB OVERLOAD(潤滑過載)

LUBE PRESSURE LOW(油霧壓力低)


SERIAL SPINDLE ALARM (串行主軸報警)

NC BATTERY LOW ALARM(NC電池低報警)

MAGAZINE MOVE LIMIT SWITCH ERROR

SPINDLE TOOL UNLAMP POSITION LIMIT SWITCH ERROR

MAGAZINE NOT IN POSITION OR SENSOR ERROR

AIR PRESSURE LOW ALARM(氣壓低報警)

MOTOR OVERLOAD(電機過載)

T CODE > MAGAZINE TOOLS

T CODE < 1 ERROR

5TH AXIS HARDWARE OVERTRAVER LIMIT ERROR

DOOR IS OPENED(開門)

LUB PRESSURE SWITCH ERROR(油壓開關錯誤)

SPINDLE OIL COOLANT UNIT ERROR

SPINDLE LOAD ABNORMAL(主軸負荷異常)

TRANSDUCER ALARM(傳感器報警)

BED-HEAD LUBRICATE OFF(床頭潤滑關閉)

EMG OFF太

HYDRAULIC CHUCK PRESS LOW(液壓夾頭壓力低)

HYDRAULIC TAIL PRESS LOW(液壓尾座壓力低)

LUB 0IL LOW(油壓低)


TURRET CODE ERROR(轉塔碼錯誤)

TURRET RUN OVERTIME(轉塔運行超時)

MANUAL HANDLE INTERRUPT

TRY TO RUN SPINDLE WHILE CHUCK NOT LOCK

TRY TO RUN SPINDLE WHILE TAIL NOT LOCK

SPINDLE NEUTRAL GEAR

MAGAZINE ADJUST

HYDRAULIC NOT RUN

SAFETY DOOR BE OPENED

SAFETY DOOR NOT CLOSE

NOT ALL AXIS HAVE GONE BACK REF

IN ADJUST,IGNORE GOING BACK REF

AFTER EXCHANGE TOOL,CYCLE START

ATC MOTOR QF16 OFF

X AXIS IS LOCKED(X 軸被鎖定)

Y AXIS IS LOCKED(Y 軸被鎖定)

Z AXIS IS LOCKED(Z 軸被鎖定)

A AXIS IS LOCKED(A 軸被鎖定)

SPINDLE MOTOR FAN QF26 OFF(主軸電機風扇QF26關閉)

關注我們的微信公眾號shukongzhpngguo,獲取更多數控技術文章。

SPINDLE ORIENTATION INCOMPLETE(主軸定位不完全)


M FUNCTION NOT COMPLETE(M 功能無法完成)

SPINDLE NOT IN GEAR POSITION(齒輪不在主軸位置)

SPINDLE NOT CHANGED TO LOW GEAR(主軸沒有變?yōu)榈蜋n)

SPINDLE NOT CHANGED TO HIGH GRAR(主軸沒有變?yōu)楦邫n)

MAG NOT BACKWARD

SPINDLE TOOL NOT CLAMP

SPINDLE TOOL NOT UNCLAMP

MAG NOT IN POSITION

MAG DOES NOT ROTATE

MAG DOES NOT STOP RUNNING

A AXIS HAVE NOT CLAMPED

A AXIS HAVE NOT UNCLAMPED

SET D499=1,"MAG.JOG" SWITCH ON

HYDRAULIC MOTOR QF7 OFF( 液壓馬達QF7關閉 )

HYDRAULIC TEMPRETURE HIGH( 液壓使用溫度高 )

HYDRAULIC FILTER BLOCKED(液壓過濾器阻止)

HYDRAULIC OIL LEVEL LOW( 液壓油位低 )

HYDRAULIC FAN QF8 OFF(液壓風扇QF8關閉)

HELIX CONYER QF9 OR QF10 OFF

CHAIN CONYER QF11 OFF


COOLANT MOTOR QF12 OFF(冷卻液電機QF12關閉)

COOLNT LEVEL LOW,CYCLE STOP AFTER 20 MINUTES

INNER COOLANT BLOCK(內冷卻堵塞)

SPINDLE COOLANT MOTOR QF14 OFF(主軸冷卻液電機QF14關閉)

INNER COOLANT QF13 OFF(內冷卻液QF13關閉)

MAG MOTOR QF15 OFF

CABINET COOLANT EQUIP QF20 OFF

OIL GATHER QF24 OFF

AIR PRESSURE LOW(低氣壓)

SPINDLE COOLANT MOTOR FAULT(主軸冷卻液電機故障)

LUB.OIL IS LOW(潤滑油低)

DOOR OPEN(門打開)

FRONT DOOR(R) OPEN(前門打開)

LEFT DOOR OPEN(左門打開)

LUBRICATION OIL QF23 OFF(潤滑油QF23關閉)

LUBRICATION PRESS LOW(潤滑油位低)

IN ADJUST,MAG CAN'T EXCHANGE T(在調整,刀庫不能交換T)

NOT ALL DOOR CLOSED(門沒有全部關閉)

IN M06,MAG NOT READY(在M06,刀庫未準備好)

MAGAZINE NOT READY(刀庫未準備好)


POCKET NOT HORIZANTAL

IN M06,Z NOT BACK TO 2ND REF

IN M06,Z AXIS NOT IN PSW1

ATC NOT IN ZERO POSITION

SPINDLE ORIENTATION UNCOMPLETE

POCKET NOT HOR./MAG NOT BCKWRD

POCKET NOT VER./MAG NOT FORWRD

UNCLAMP TOOL HAS NOT COMPLETED

CLAMP TOOL HAS NOT COMPLETED

AIM TOOL NO. IS WRONG

MAG NOT BACKWARD

AFTER RETRACT,SET R.T.BACK OFF

Z NOT IN PSW2,FORBID ATC RUNNING

D499 EQUAL 1

MAG.JOG SOFT SWITCH IS ON

Z NOT IN PSW2,FORBID MAG FORWARD

CHEKE SPINDLE MODULE ALARM

OIL WATER SEPARATOR QF24 OFF

SET THE SOFT SWITCH MAG.JOG OFF

SET D499 TO 0 設定D499為0


K PARAM ABOUT MAG SET IS WRONG 關于MAG的K參數設定錯誤

MECHANICAL BRAKE NOT RELEASED機床抱閘沒有松開

MECHANICAL BRAKE IS WRONG 機床抱閘錯誤

PLEASE ADD LUB.OIL 請加潤滑油

PROBE BATTERY VOLTAGE IS LOW 探頭電池電壓低

PROBE IS ERR 探頭錯誤

PARAMETER WRITE ENABLE(參數寫使能)

PMC EDIT ENABLE(PMC編輯使能)

CHECK LUB ROUTIN

SPINDLE GEAR SIGNAL MISS 主軸檔位信號消失

T_CLAMPED_SIGNAL MISS T夾緊信號消失

SP OVERRIDE SWITCH DISCONNECTION 主軸倍率開關斷路

FEED OVERRIDE SWITCH DISCONNECTION 進給倍率開關斷路

THE TOTAL NUMBER OF POCKETS SET ERR

CHANGE T STOPED BECAUSE NO AIR 因?yàn)槿鄙賶嚎战粨Q停止

THE COOLANT WATER TOO LOW,ADD COOLANT WATER AT ONCE 冷卻水少立即加水

COOLANT LEVEL LOW,ADD COOLANT WATER 冷卻水液位低

PLEASE REPLACE CNC BATTERY QUICKLY 請立即更換CNC電池

有些還沒有翻譯,僅供參考。


SIEMENS常用縮略語

A Output 輸出

ASCII American Standard Code for Information Interchange 美國信息交換標準代碼

AV Preparation for work 運行準備

BA Operating mode 運行方式

BAG Operating mode groups 運行方式組

BB Ready for operation 準備好運行

BCD Binary Coded Decimals 二-十進制

BHG Hand-held terminal 手提終端

BOF User interface 用戶接口

CNC Computerized Numerical Control 計算機化數字控制

CP Communication Processor 通迅處理器

CPU Central Processing Unit 計算機中央處理裝置

CR Carriage Return 托架折回

CSB Central Service Board(PLC module) 中央維護板,PLC 模塊

CTS Clear To Send 發送使能

DAU Digital-Analog Converter 數模轉換器

DB Data Block 數據塊

DIN German Industrial Standards 德國工業標準


DIO Data Input/Output 數據輸入/輸出

DRF Differential Resolver Function 差分功能

DRY Dry Run 空運行

DSB Decoding Single Block 譯碼單段

DSR Data Send Ready 備用輸入

DW Data Word 數據字

E Input 輸入

EIA-Code Special tape code,number of holes per characters always odd 特殊紙帶碼,每個字符的孔數為奇數

EPROM Programm memory with fixed program 有固定程序的程序存儲器

E/R Controlled Supply and Energy Recovery Module 可控電源和能量恢復模塊

ETC ETC key:Extension of the softkey bar in the same menu

ETC 鍵:同級菜單擴展鍵

FDB Product designation database 產品指定數據庫

FIFO First in First Out 先進先出

FRA Frame module 幀頻模塊

FRAME Coordinate conversion with the components zero

offset,rotation,scaling,

mirror-imaging 坐標換算,具有零點偏置,坐標旋轉,標度功能和鏡向功能

FRK Cutter radius compensation 銑刀半徑補償


FST Feed Stop 停止進給

GUD Global User Data 全體用戶數據

HMS High-Resolution Measuring System 高分辨率測量系統

HSA Main Spindle Drive 主軸驅動

HW Hardware 硬件

IM Interface Module 接口模塊

IM-S/R Interface Mo
